The Eye-Pentagon Construction

Requires a Wolfram Notebook System

Interact on desktop, mobile and cloud with the free Wolfram CDF Player or other Wolfram Language products.

Requires a Wolfram Notebook System

Edit on desktop, mobile and cloud with any Wolfram Language product.

With a ruler and compass, an eye is easy to construct, leading to a regular pentagon construction. First draw a unit circle centered at O, the pupil. With centers at the top and bottom of the pupil, draw two circles of radius 2 to form the eyelids. Using the top of the pupil (A) as the center, draw an arc of radius 1 (AO) to intersect the upper eyelid at B. With C as the left corner of the eye, draw an arc with radius OC, and then a larger arc with radius BC. Draw a final arc with radius BC centered at O. Connect the intersection points for the pentagon.

Contributed by: Ed Pegg Jr (March 2011)
Open content licensed under CC BY-NC-SA
